Omron NX-CIF105

Brand：Omron
Model：NX-CIF105

Inventory situation: Goods are available in stock.

Product features

The Omron NX-CIF105 is a high-performance industrial communication module designed for seamless integration in automation systems. As part of Omron's advanced NX series, this compact unit supports RS-422A/485 protocols, enabling efficient data exchange between devices in manufacturing plants, assembly lines, and process control applications. With its 12mm width and screwless push-in connector, the NX-CIF105 saves space and reduces wiring time, making it ideal for systems where space is limited.

Featuring a maximum transmission speed of 230.4 kbps, the NX-CIF105 ensures fast and reliable communication with serial devices like sensors, PLCs, and HMIs. It supports half-duplex communication for two-wire connections and full-duplex for four-wire setups, offering flexibility in various industrial networks. The module's non-protocol communication method allows simple setup and compatibility with different devices, while its data backup function from the EtherCAT coupler unit enhances maintainability.

The NX-CIF105 is widely used in applications such as temperature control systems, where it establishes stable Modbus-RTU communication with devices like the E5CC thermostat. Its IP20 protection rating and robust design ensure reliable operation in harsh industrial environments, withstanding vibrations and shocks as per IEC standards. Whether you need to connect serial devices to an EtherCAT network or integrate legacy systems into modern automation setups, the Omron NX-CIF105 delivers efficient, cost-effective solutions. Explore the benefits of this versatile module for your industrial automation needs.

Specifications

Communication interface	RS-422/485, supports protocol-free communication
Baud rate range	1,200 to 115,200 bps (configurable)
Communication distance	Up to 15 meters (RS-485 mode, depending on cable type)
Dimensions	12mm × 100mm × 80mm (W × H × D)
Weight	approximately 69g (including terminal block)
Mounting method	DIN rail mounting
Protection level	IP20
Safety certifications	cULus (UL508), EN 61131-2, RCM, etc.

Product Application Scenarios

One key application of the NX-CIF105 is temperature control in manufacturing processes. For example, it can establish seamless Modbus-RTU communication with devices like the Omron E5CC temperature controller. This allows real-time monitoring and adjustment of temperature parameters, ensuring precision in industries such as food processing or electronics production. The unit's support for RS-422/485 protocols and high transmission speeds up to 230.4 kbps make it ideal for transmitting data over long distances in factory environments.

In industrial automation systems, the NX-CIF105 enables integration of multiple devices into a single network. It works seamlessly with the SYSMAC Studio software, providing users with real-time diagnostics through its serial line monitor function. This feature helps identify communication issues quickly, reducing downtime. Additionally, its compact design (only 12 mm wide) saves space in control panels, making it suitable for systems where space is limited.

The NX-CIF105 also excels in data acquisition and monitoring. By connecting sensors and actuators, it collects critical data for analysis and control. For instance, in a production line, it can gather data from pressure sensors or flow meters and transmit it to a central control system. This data-driven approach enhances efficiency and quality control.

When paired with devices like the Mitsubishi FX5-4DA-ADP, the NX-CIF105 expands its capabilities. The FX5-4DA-ADP is an analog output module that converts digital signals to precise analog values. Together, they can create a hybrid system where the NX-CIF105 handles communication while the FX5-4DA-ADP ensures accurate control of analog devices such as valves or motors. This combination is widely used in process automation for industries like chemical manufacturing or water treatment.

FAQ

Q: What is the Omron NX-CIF105 communication interface module?

A: The Omron NX-CIF105 is a high-performance industrial communication interface module designed for seamless data exchange in automation and control systems. Supporting RS-422 and RS-485 protocols, it ensures reliable communication between industrial devices, making it ideal for factory automation and industrial IoT applications.

Q: What communication protocols and data rates does the Omron NX-CIF105 support?

A: The module supports protocol-free serial communication with a configurable baud rate range from 1,200 to 115,200 bps. This flexibility makes it suitable for various industrial automation projects, including industrial Ethernet and serial device communication.

Q: What is the maximum communication distance of the Omron NX-CIF105?

A: In RS-485 mode, the maximum communication distance is up to 15 meters. This feature is perfect for connecting industrial equipment over long distances on factory floors, ensuring stable and robust data transmission.

Q: What are the dimensions and installation options for the Omron NX-CIF105?

A: The compact size of 12mm × 100mm × 80mm makes the NX-CIF105 easy to install in tight spaces. It supports DIN rail mounting, making it compatible with control cabinets and automation systems in manufacturing environments.

Q: What are the IP protection level and safety certifications of the Omron NX-CIF105?

A: With an IP20 protection rating, the module is suitable for industrial environments. It has achieved safety certifications including cULus (UL508), EN 61131-2, and RCM, ensuring compliance with international safety standards.
