Allen Bradley 22A-D4P0N104

Brand：Allen Bradley
Model：22A-D4P0N104

Inventory situation: Goods are available in stock.

Product application scenarios

In manufacturing assembly lines, the 22A-D4P0N104 excels at controlling conveyor belt motors. It adjusts belt speed dependent on the number of parts moving-slowing down when workers require more time and speeding up during peak productivity. Its built-in overload protection shuts off the motor if it becomes too hot, eliminating malfunctions and keeping the line operating smoothly. This Allen Bradley drive also works well with sensors, so if a sensor detects a jam, it can instantly slow the belt to correct the problem, minimizing downtime.

The 22A-D4P0N104 is used in food and beverage companies as packaging machines. It regulates the motors of bottle cappers and labelers, ensuring that each container is sealed or branded uniformly. The drive's dust-resistant design fits well in clean manufacturing locations, and its ability to work with low-voltage signals keeps it safe in washdown zones (when correctly installed). This makes it an excellent alternative for food-safe areas where hygiene and consistency are critical.

In warehouse logistics, the 22A-D4P0N104 provides power to small lifting motors in automated storage systems. When transferring boxes, it adjusts the pace of lift platforms to ensure that they stop exactly at the correct shelf level. Its straightforward interface with PLCs (programmable logic controllers) enables warehouse managers to build up simple automated routines, such as lifting a platform when a sensor detects a box, resulting in faster and safer material handling.

Dimensions and Specifications

Device Dimensions	160 x 100 x 250 mm (W * H * D)
Weight	Approximately 2.8 kg
Power Supply Voltage	AC 100-240 V,
Power Consumption	Approximately 4KW
Operating Temperature Range	0 to 50 °C
Storage Temperature Range	-40 to 85 °C
Storage Humidity	10 to 95 %(No condensation.)
Output Frequency Range	0 to 400 Hz
Control Method	Support for V/f control and vector control

Product features

The 22A-D4P0N104 uses sensorless vector control to provide smooth torque and speed adjustment even under fluctuating loads. It accepts 380-480V AC input voltage and outputs at 0-240Hz, giving it flexibility in a variety of voltage environments. The drive has overvoltage and undervoltage protection to protect against power fluctuations, with trip points of 810V DC (575V AC) and 390V DC (275V AC), respectively.

The 22A-D4P0N104 is designed for endurance, with an IP20-rated housing and a panel mount design that makes it appropriate for tough industrial environments. Its small dimensions (140x184x151mm) and space-saving design make installation easier, while the integrated LED keypad allows for simple parameter control and status monitoring. The drive additionally has three fixed inputs (start/stop/rev), two programmable inputs, and analog channels for 0-10V DC or 4-20mA signals.

The 22A-D4P0N104 includes an RS485 communication interface that supports Modbus and DeviceNet protocols, allowing for simple interaction with PLCs and other automation systems. It complies with international market requirements by meeting global standards such as UL and CE. While the drive lacks a CE-compliant filter, it does have a brake chopper enabling rapid motor stops in applications such as elevators or cranes.

Please be aware that the 22A-D4P0N104 has been discontinued, and Rockwell Automation suggests upgrading to the 25A-D4P0N104 PowerFlex 523 drive for new applications. Existing systems, however, continue to be serviced with new parts and repairs. Regular maintenance, such as wiring inspection and firmware updates, can extend the drive's life and prevent typical problems like overheating and communication difficulties.
