Siemens 6AV7861-2TB10-2AA0

Brand: Siemens
Model: 6AV7861-2TB10-2AA0

Inventory situation: Goods are available in stock.

Product features

Siemens 6AV7861-2TB10-2AA0 is a dependable industrial flat panel touchscreen from Siemens' SIMATIC series, designed specifically for industrial automation and machine control applications.The Siemens 6AV7861-2TB10-2AA0 has a 15-inch TFT color touchscreen with a resolution of 1024×768 pixels (XGA), providing crisp and sharp pictures that are easy to read. With a brightness of over 260 cd/m² and a contrast ratio of 350:1, it offers good visibility in both bright and dim industrial conditions. Its 170-degree broad viewing angle also allows operators to engage with the panel from a variety of locations without affecting image quality, making it ideal for team collaboration.

The Siemens 6AV7861-2TB10-2AA0 offers a variety of connecting options to accommodate various industrial configurations. It has VGA and DVI-D video inputs for smooth display connections, two USB Type A ports, one USB Type B port for data transfer, and two serial com interfaces. Notably, COM2 offers three connection modes-RS232, RS485, and RS422-that may be selected from the BIOS menu, providing the flexibility to communicate with a variety of industrial devices. This touchscreen's maximum connection distance of 30 meters enables for flexible installation in big factories or machine rooms.

The Siemens 6AV7861-2TB10-2AA0, designed for industrial endurance, functions smoothly in temperatures ranging from 0°C to 50°C during operation and can be safely stored between -20°C and 70°C. It is resistant to vibration and stress, making it appropriate for severe industrial environments. The touchscreen is powered by a 24V DC or 120/240V AC (50-60Hz) power supply, making it compatible with many factory power systems. The backlight has a mean time between failures (MTBF) of 50,000 hours, ensuring long-term stability and low downtime.

Specifications

Model	6AV7861-2TB10-2AA0
Product Type	15-inch TFT Touch Screen
Resolution	1024 x 768 pixels (XGA)
Brightness	>260 cd/m²
Contrast Ratio	350:1
Viewing Angle	170 degrees
Input Voltage	24V DC or 120/240V AC
Interfaces	VGA, DVI-D, USB (A x 2, B), COM (x 2)

Application scenarios

The Siemens 6AV7861-2TB10-2AA0 is mostly used in manufacturing production lines. This touchscreen is used in factories that produce electronics, machinery parts, and consumer items to allow workers to monitor equipment status, modify production parameters, and track workflow in real time. The 15-inch XGA display (1024×768 pixels) and over 260 cd/m² brightness offer clear visibility even in busy, well-lit factories. The 170-degree broad viewing angle lets numerous team members to review data from different areas, making it ideal for collaborative operations on assembly lines. With USB and serial interfaces (including RS232/RS485/RS422 capability), it connects readily to sensors, programmable logic controllers (PLCs), and other production tools, making it an essential HMI for small to medium manufacturing plants.

The Siemens 6AV7861-2TB10-2AA0 performs well in machine control stations for packaging machines, conveyor systems, and robotic arms. Industrial equipment frequently operate in tough situations with vibration or temperature variations, but this touchscreen's shock-resistant design and operating temperature range of 0°C to 50°C ensure that it runs smoothly. Operators utilize the touch feature to start and stop equipment, diagnose small faults, and set operational modes, all through an easy-to-use interface. Its 50,000-hour backlight MTBF reduces maintenance downtime, which is crucial for keeping machine-driven processes running on time.

FAQ

Q: What is the Siemens 6AV7861-2TB10-2AA0?

A: The Siemens 6AV7861-2TB10-2AA0 is a model from the SIMATIC HMI Basic Panel family. According to Siemens' product categorization, this is a Human-Machine Interface (HMI) touch panel for industrial automation operator control, process visualization, and machine monitoring. For exact technical details, please refer to the official Siemens SIMATIC HMI datasheet for this catalog number.

Q: What software is used to program the 6AV7861-2TB10-2AA0 HMI?

A: This panel can be programmed via the Siemens TIA Portal. The integrated SIMATIC WinCC software in TIA Portal is used to create visualization projects, configure alarms, and establish connectivity with your PLCs.

Q: Can the 6AV7861-2TB10-2AA0 communicate with non-Siemens PLCs?

A:Its primary and most optimized integration is with SIMATIC controllers over PROFINET or PROFIBUS. Communication with third-party PLCs may be feasible via universal protocols such as Modbus TCP or Modbus RTU (if enabled by the specific model's interface settings), although capability may be reduced when compared to native Siemens integration.
