Product Specifications
Resolution: 16 bits
Quantity: With 8 channels
Working temperature: -20℃~60℃
Type of installation: DIN rail installation
Sampling data: supports sampling frequency of hundreds of times per second
Input resistance: The input resistance of the voltage input is greater than 10MΩ, and the input resistance of the current input is 250Ω.
Product Features
1. Can be paired with MTU TU884 or TU845. After matching, each channel can be flexibly switched to voltage or current input mode, which can meet your diverse needs for input signal types under different working conditions and effectively reduce costs and complexity.
2. It has an excellent design of ground isolation, which blocks external interference and effectively reduces the external impact on the collected signal.
3. It can protect the module itself and the entire control system from potential electrical faults.
4. In the scenario where the transmitter needs to be powered, the AI845 module has obvious advantages. It can distribute external HART-compatible power to each channel, and can power 2-wire or 3-wire transmitters, greatly simplifying wiring and connections, and effectively reducing installation workload and cost.
5. This module can monitor the power of the transmitter and limit the current, which can ensure the normal operation of the transmitter, avoid failures and protect the module, improve the stability of the system and make it run more smoothly.
6. This module has advanced on-board diagnostic functions and can monitor a variety of modules and channel errors. System faults can be quickly and accurately prompted, facilitating maintenance and inspection, significantly reducing downtime and maintenance costs and improving system maintainability and availability.
Product Features
1. Conversion of analog signals
2. Support multiple input methods
3. Power supply management
4. Channel isolation
5. Diagnostic monitoring
6. Communication functions
