Siemens 6AV3607-1JC30-0AX1

Brand: Siemens
Model: 6AV3607-1JC30-0AX1

Inventory situation: Goods are available in stock.

Product features

The Siemens 6AV3607-1JC30-0AX1 features a PROFIBUS DP interface that meets the EN 50170 standard and has a maximum communication speed of 12 Mbaud. This enables seamless data communication between Siemens controllers such as S5, 505, S7, and M7, as well as suitable devices such as S7-200/300 PLCs and G120 frequency converters. The panel employs key operation, which is straightforward and intuitive-even workers wearing gloves can operate it correctly, making it perfect for busy industrial settings.

In terms of power supply, the Siemens 6AV3607-1JC30-0AX1 operates at 24V DC and consumes only 190 mA, making it energy efficient and lowering operational costs. Its physical design is modest and practical: weighing only 0.5 kg, it may be simply mounted on a 35 mm DIN rail, conserving space in control cabinets. The front of the panel has an IP65 protection certification (IEC 60529), making it dust-tight and resistant to water jets-ideal for resisting metal dust, coolant splashes in machine shops, and cleaning sprays in food packaging operations. The rear of the panel is IP20 rated, which ensures internal circuit safety in controlled cabinet situations.

This industrial operator panel works well under tough conditions. It runs smoothly between 0°C and 55°C and can be stored or transported in temperatures ranging from -25°C to 70°C. It can withstand relative humidity levels of up to 95% without condensation, making it suitable for a variety of workplace situations such as food processing factories and water treatment facilities. With UL/CSA certification and compliance with industrial electromagnetic compatibility standards, the Siemens 6AV3607-1JC30-0AX1 fulfills stringent global industrial safety standards.

Specifications

Model	6AV3607-1JC30-0AX1
Product Series	SIMATIC HMI
Display Type	Monochrome LC Display (LCD)
Number of Display Lines	4 lines
Characters per Line	20 characters
Backlight Type	LED backlight
Interface Type	PROFIBUS DP
Communication Rate	Up to 12 Mbaud

Application scenarios

Siemens 6AV3607-1JC30-0AX1 serves as a core control terminal for small and medium-sized machine tools such as CNC lathes, milling machines, and drilling machines. It communicates with the S7-200 PLC via the PROFIBUS-DP interface, collecting and displaying processing parameters such as spindle speed, feed rate, and processing temperature in real time. The programmable keys allow operators to execute start-stop, feed direction adjustment, and emergency stop commands. Its IP65 protection rating allows it to withstand metal dust and coolant spills during machine processing, ensuring reliable operation even in severe workshop conditions. Meanwhile, its compact design enables for easy installation in the narrow spaces of machine tool control cabinets, resulting in significant space savings.

Siemens 6AV3607-1JC30-0AX1 is also commonly used in food packaging machinery, such as biscuit packaging machines, beverage filling machines, and mask packaging machines. It communicates with sensors and a S7-300 PLC on various production lines to monitor packaging speed, sealing temperature, and material surplus. The screen allows operators to switch between packaging techniques and alter package characteristics. The IP65 protection grade makes it resistant to cleaning and disinfection in food workshops, and its wide operating temperature range (0°C to 55°C) conforms to the air-conditioned environment of food production sites, ensuring consistent monitoring of the packaging process.

FAQ

Q: What is the Siemens 6AV3607-1JC30-0AX1?

A: The Siemens 6AV3607-1JC30-0AX1 is an original operator panel (also known as OP 7-DP12) designed for industrial automation systems, specifically for use with Siemens Programmable Logic Controllers (PLCs) such as the S7 series. It functions as a robust human-machine interface (HMI) for monitoring and operating machinery in environments such as CNC machines and other industrial equipment.

Q: What software is required to program or configure this Siemens HMI panel?

A: The 6AV3607-1JC30-0AX1 (OP 7-DP12) is an older model. Previously, generating operational projects (or "configurations") required older, proprietary Siemens HMI configuration software. According to community debates, newer versions of WinCC Flexible may not support older hardware. Instead, it is recommended to utilize ProTool, a specific software for traditional operator panels.

Q: Is there a direct replacement or upgrade for the 6AV3607-1JC30-0AX1?

A: Yes.Siemens has offered an updated model. The official replacement for the 6AV3607-1JC30-0AX1 (OP 7-DP12) is the 6AV3607-1JC30-0AX2. If you are upgrading a system, it is strongly advised to pick this newer model or the most recent generation of Siemens HMI panels for improved software support and functionality.
