Omron CP2E-N14DR-A

Brand：Omron
Model：CP2E-N14DR-A

Inventory situation: Goods are available in stock.

Application scenarios

The Omron CP2E-N14DR-A PLC excels at packaging systems, including sealing machines and labeling equipment. Its relay outputs can withstand high voltage loads, powering solenoids and motors for accurate packaging operations. The 4-axis linear interpolation capability (available in CP2E-N models) allows for precise positioning, such as aligning labels or cutting materials to specific measurements. Additionally, it offers temperature control via function blocks, ensuring stable conditions for heat-sealing procedures.

In warehouses, the CP2E-N14DR-A controls automated storage and sorting conveyors. Its Ethernet connectivity enables integration with warehouse management systems (WMS) for real-time inventory tracking. For example, it can use sensor feedback to control the movement of AGVs (Automated Guided Vehicles), thereby increasing material handling efficiency. The PLC's compact size and wide temperature range make it ideal for demanding warehousing situations.

The CP2E-N14DR-A is ideal for stand-alone machines such as mixers, compressors, and test equipment. The processor's 10k-step program memory and 0.23 µs logic execution time enable efficient handling of complex jobs. For example, it can automate a tiny CNC machine by managing spindle speed and tool movements in response to input commands. The built-in user program recovery feature ensures that execution continues even if mistakes occur.

Specifications

Device Dimensions	100 x 85 x 60 mm (W * H * D)
Weight	Approximately 0.5 kg
Power Supply Voltage	100-240 V AC, 50/60 Hz (includes 24 V DC version)
Power Consumption	approximately 36VA (under AC power)
Operating Temperature Range	0 to 55 °C
Storage Temperature Range	-25 to 65 °C
Storage humidity	10 to 90% (non-condensing)

Product Features

The Omron CP2E-N14DR-A is a versatile programmable logic controller (PLC) that excels at small-scale industrial automation. As a core model in Omron's CP2E family, the CP2E-N14DR-A is designed to handle simple control duties with simplicity, making it a popular choice for small factories, workshop machinery, and smaller production lines.

The Omron CP2E-N14DR-A has 14 I/O points, including eight digital inputs and six relay outputs. The inputs accept DC 24V signals, making them ideal for connecting to sensors, limit switches, and push buttons, all of which are commonly used in industrial settings. The relay outputs can handle AC 250V or DC 30V, making them ideal for operating small motors, indicator lights, and solenoid valves in devices such as micro packing machines or small assembly stations.

The CP2E-N14DR-A, which operates on an AC 100-240V supply, is simple to install in most workshops. Its small dimension (about 100mm x 85mm x 60mm) saves room in control boxes and allows for easy installation on DIN rails. It operates effectively in temperatures ranging from 0°C to 55°C and can withstand the heat of busy manufacturing environments without trouble.

Programming the Omron CP2E-N14DR-A is simple with Omron's CX-Programmer software, which employs ladder logic, a visual style that is simple for new users to grasp. It has 4,000 program steps, which is sufficient for activities such as timing conveyor belts or operating small-scale material handling equipment. It also includes built-in timers and counters for more versatility in daily industrial applications.

FAQ

Q: What is the Omron CP2E-N14DR-A used for?

A: The Omron CP2E-N14DR-A is a compact PLC designed for small to medium industrial automation systems. It controls machinery in packaging, conveyor belts, and factory equipment. With 8 digital inputs and 6 relay outputs, it handles both low-voltage signals (sensors/switches) and high-power loads (motors/solenoids). Ideal for space-constrained applications, it integrates Ethernet TCP/IP for remote monitoring and data collection.

Q: What voltage range does the CP2E-N14DR-A support for inputs?

A: The inputs accept DC 24V ±10% (21.6V to 26.4V), compatible with both PNP and NPN sensors. This flexibility reduces the need for external voltage converters.

Q: Is the CP2E-N14DR-A compatible with other Omron PLCs?

A: Yes! It works seamlessly with the CP1E, CP1L, and CPM1A series via common programming software and communication protocols.

Q: What are the basic specifications of the Omron CP2E-N14DR-A?

A: The Omron CP2E-N14DR-A is a compact PLC from the CP2E-N Network Series. It provides 14 total I/O points, comprising 8 digital inputs and 6 relay outputs. The unit operates on an AC power supply of 100 to 240 VAC at 50/60 Hz, with an operating voltage range of 85 to 264 VAC. It is designed for DIN rail mounting and measures 90 mm (height) × 80 mm (depth) × 86 mm (width). The maximum weight of this CPU unit is 335 g.

Q: What are the program and data memory capacities of the CP2E-N14DR-A?

A: The CP2E-N14DR-A features 10K steps of program memory (with an additional 10K steps for the function block program area) and 16K words of data memory. The function block capacity is also 10K steps, enabling structured programming for more complex machine control applications.

Q: What is the processing speed of the CP2E-N14DR-A?

A: The CP2E-N14DR-A executes logic instructions in 0.23 µs per instruction, delivering fast scan cycle performance for time-critical automation tasks. This high-speed processing capability makes the Omron CP2E-N14DR-A suitable for applications requiring rapid I/O response and real-time control.
